classic-pro Installation ID MAX50.10-E/-RE
FEIG ELECTRONIC GmbH Page 31 of 39 M90802-1de-ID-B-FCC.doc
E N G L I S H
8.1.3. Connection with PoE Supply
PoE Power Supply
(IEEE802.3af)
Ethernet
Ethernet
ID CPR.IO
ID CPR50.10-E
Door Contact
X3
4
3
5
6
