Manual MWD BPC
FEIG ELECTRONIC GmbH Page 16 of 23 MWD BPC_Handbuch_mehrsprachig_1.doc
2 General
The MWD BPC Radar Motion Detector operates with a planar microwave antenna and is used on industrial
gates for entry and access recognition.
The device is intended for installation outdoors and is preset for typical gate applications.
The device is operated via the connected door controller. Thereby, the operator prompting is done using the
display of the door controller.
The two output relays provided can be adjusted independently from each other in many ways.
The approach sensitivity and the direction logic can be adjusted for both channels of the motion detector.
The detector can also distinguish between people and vehicles and suppress cross-traffic.
3 Technical Data
Case dimensions (W x H x D): 135x65x130 mm
Material
Case and retaining bracket
Cover
ASA
PC
Weight with retaining bracket 160 g
Protection class IP65
Supply voltage 12-27 V AC, 50 – 60 Hz
12-30 V DC, GND must be connected to PE.
SELV, limited capacity power source according to EN 60950-1
Power consumption typical. 1.0W
max. 2.4W
Permissible operating temperature
Storage temperature
Relative humidity
-20 °C to +55 °C
-30 °C to +75 °C
< 95% non-condensing
Frequency 24.125 GHz
Transmission power typical. 40 mW EIRP
max. 100 mW EIRP
Maximum mounting height 7m
Display 2 LED
Text messages with door controller display
Connection Input (IN), CAN + Supply, M8-SnapIn Male
Output (OUT), CAN + Supply, M8-SnapIn Female
Networking Up to 4 motion detectors on one door controller
If the device becomes unusable, dispose it in accordance with the current statutory
regulations !
