6 Display during use
Fig. 6: LED´s
State LED 1, yellow LED 2, red
No supply voltage Off Off
Supply voltage OK 1Hz permanent Off
CAN-Error Off 4Hz permanent
Chanel 1 Object recognised On X
Chanel 2 Object recognised X On
Chanel 1 + 2 Object recognised On On
Detector selected in door controller 2Hz permanent synchronous 2Hz permanent synchronous
