9 Performance Features
The Shielded Pad Reader ID ISC.SPAD102 is designed for reading passive data carriers, so-
called “Smart Labels,“ at an operating frequency of 13.56 MHz with a maximum output power of
1,5 W. The ID ISC.SPAD102 is suitable for all applications in which moderate reading distances
are required. A shielded antenna and a reader are integrated in a plastic housing.
Due to the shielding the communication with the transponder is widely limited on the top area of
the antenna.
The ability to place the antenna ID ISC.SPAD102 directly on metal without changing the antenna
parameter is a second essential advantage of this antenna.
An anti-collision function enables simultaneous reading of up to 30 transponders per second.
The antenna may be used for detecting both product or persons. The preferred orientation of a
Smart Label is parallel to the antenna surface. The maximum range is achieved over the center of
the antenna surface.
9.1 Order Reference
The following variants are available currently:
Table 9-1: Order reference Shielded Pad-Reader
Shielded Pad Reader with USB Interface
Shielded Pad Reader with Ethernet Interface
9.2 Scope of delivery
Within the scope of delivery the reader ID ISC.SPAD102 came including assembly and mounting
instruction.
9.3 Cleaning
Attention! The surfaces should be cleaned with a clean, soft cloth dampened in a
dishwashing liquid – water solution. The use of alcohol, spirit, thinners, glass clean-
ers or other harsh cleaning liquids is prohibited and will damage the acrylic plate.
