Feig Electronic OBID i-scan UHF User Manual

OBID i-scan
®
UHF
Installation
ID ISC.LRU1002
FEIG ELECTRONIC GmbH
Page 23 of 29
M31010-1e-ID-B.docx
6.
Technical Data
MECHANICAL DATA
Housing
Aluminum powder-coated
Dimension (W x H x D)
261,3 mm x 157,3 mm x 68 mm)
10.29 inch x 6.19 inch x 2.68 inch
Weight
1,8 kg (4.0 lb)
Protection Class
IP 53 (with protection cap IP64)
Colour
RAL 9003 (Signal White)
ELECTRICAL DATA
Power Supply
24 V DC ± 5 % (Noise Ripple: max. 150 mV)
Power Consumption
max. 18 W
Operating Frequency
 EU-Reader
 FCC-Reader
865 MHz to 868 MHz (EN 302208)
902 MHz to 928 MHz (FCC47 Part15)
RF-Power
100 mW to max. 2 W configurable
Antenna Connection
4 x SMA female (50 ), internal Multiplexer
Outputs
 2 x Optocoupler
 1 x Relay)
24 V DC / 30 mA (galvanically isolated)
24 V DC / 1 A (switching current), (2A con-
stant load)
Inputs
 1 x Optocoupler
max.24 V DC / 20 mA
Interfaces
RS232, USB (full Speed), Ethernet, Data-Clock
