FEIN – REPAIR - TOOLS
All rights reserved by FEIN, especially in case of industrial rights registration.
Any power of disposition such as copying and right of transfer is situated with FEIN.
Sahre / MVK 05 / 2011
4.3. Disassembly - Drill motor
Remove 2 screws from cover cap
Remove cover
Loosen and remove screw for securing housing
Remove safety shutdown mat
Tools:
- cross slotted screw driver PH 2
