FEIN – REPAIR - TOOLS
All rights reserved by FEIN, especially in case of industrial rights registration.
Any power of disposition such as copying and right of transfer is situated with FEIN.
Sahre / MVK 05 / 2011
4.4. Disassembly - Gearbox
Remove grease from gearbox
Remove intermediate gear from gearbox housing
Warning – it is best to remove the large intermediate gear when the gear
converter is in first gear
Warning – the intermediate gear with slipping clutch is only available as
a complete spare part, because the slipping clutch is pre-set
