5.3. Assembly - Gearbox
Insert switching handle and secure with circlip
Place shifting claw in housing and move switching handle pin
into guide
Insert and tighten thread bolt (best to do this in first gear switch
position)
Tool:
- Slotted screwdriver
- External circlip pliers
