5.4. Assembly - Feed unit
Insert selector shaft into shaft
Insert switch bar and fix with dowel pin
Screw handles into switch bolts
!!! Warning – replace cylinder pins and switch bar after every disassembly process,
because the press-fitting is damaged during disassembly !!!
Tool:
- Punch
- Steel hammer
