FEIN – REPAIR - TOOLS
All rights reserved by FEIN, especially in case of industrial rights registration.
Any power of disposition such as copying and right of transfer is situated with FEIN.
Sahre / MVK 05 / 2011
3. General checks
Rated voltage 220 - 240 V
Test voltage / 10 % 230 V
Idling current / 10 % (3.40 – 4.00 A) 3.7 A
Idling speed, first gear / 5% (162 - 198 rpm) 180 rpm
Main switch on
Voltage on X5 10% (90-110 VDC) 100 VDC
Release force of magnet >= 3,500 N
Current consumption of magnetic foot Approx. 0.15 A / AC
Main switch on, motor on
Voltage on X5 10% (180-220 VDC) 200 VDC
Resistance of magnetic foot per coil 22 ohms
Test voltage - motor without electronics 145 VAC
