FeiYu Tech Pocket 3 - Waterproof Case (Optional)

- 11 -
Steps for installation(Take remote handle as an example)
(1) Take o󽗈 the expansion base, and slide the magnetic base (the bottom part of Feiyu
Pocket 3) in as shown in the 󽗉gure. And make the ball on the extension bar clip in the
dovetail slot.
(2) Slide the bottom part of extension bar in the remote handle, and make the ball on
the extension bar clip in the dovetail slot.
(3) Toggle down the lever on the bottom of the extension bar to lock.
3
1
2
6.4 Waterproof Case (Optional)
[1] Waterproof cover
[2] Securing ring
[3] Power button
[4] Shutter button
[5] Wrist strap hole
[6] 1/4 inch thread hole
[3]
[4]
[1]
[2]
[6]
[5]
