- 7 -
Remove: Unlock the quick release plate safety lock ① , remove the quick release
plate while pressing anti-drop column ④ .
4
1
Vertical mounting
Unlock the vertical quick release plate safety lock ⑤ , push the plate with the
mounted camera into the slot ⑥ , lock the safety lock ⑤ once the camera is roughly
balanced.
5
6
7
5
Remove: Please refer to the remove steps for horizontal mounting. Unlock the quick
release plate safety lock ⑤ , remove the quick release plate while pressing anti-drop
column ⑦ .
