- 2 -
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[30]
[31]
[32]
[33]
[34]
[35]
[36]
[37]
[38]
[40]
[41]
[P3][P4]
[39]
[1] Touch Screen
[2] Shutter button
[3] Joystick
[4] Handle mode button
[5] Customizable button
[6] Handle power button
[7] Handle lock
[8] Gimbal mode button
[9] Gimbal power button
[10] Type-C charging port
[11] Tripod
[12] Pan lock
[13] Pan axis
[14] Vertical arm
[15] Roll lock
[16] Slide arm
[17] Tilt axis
[18] Vertical quick release
plate safety lock
[19] Tilt lock
[20]
Cross arm extending position knob
[21] Cross arm
[22] Roll axis
[23] Slide arm lock knob
[24] Camera backing base
[25] Quick release plate
[26] Lens holder
[27] Lens holder screw
[28] Vertical arm lock knob
[29] Knob function switching button
[30] Trigger button
[31] Multifunction knob (Main knob)
[32] A /B /C button (Record Mark
points)
[33] Remote control handle
[34] Multifunction knob
(Handle knob)
[35] Focusing wheel
[36] Cross arm lock knob
[37] Vertical mounting plate
[38] Quick release plate safety
lock
[39] Anti-drop column
[40] Slider lock
[41] Fixed plate slider
[P1] Camera control port
[P2] Image transmission port
[P3] Extension port 1
[P4] Extension port 2
