FEIYUTECH G6 Max - Balance Adjustment of the Pan Axis

(3) If the camera cannot be parallel with the
horizontal plane after balancing, please
unlock the safety lock, and slide the quick
release plate until the camera is parallel with
the horizontal plane, then lock the safety lock.
07
www.feiyu-tech.cn
Pan Axis Knob
Ring
Loosen
Vertical Armmove
Horizontal Plane
Cross Arm
move
Roll Axis Knob
Ring
Loosen
Balance Adjustment of the Pan Axis
3
(1) Unlock the pan axis position lock, hold the
gimbal horizontally, make the handle is parallel
with the horizontal plane.
(2) Loosen the pan axis knob ring, slide the
vertical arm to balance the camera. Then tighten
the pan axis knob ring, and rotate the pan axis to
any angles, if the camera can stay stable means
balanced.
* Please tighten the pan axis knob ring after balanced the pan axis.
Steps
* Please lock the safety lock after balanced
the roll axis.
Quick Release
Plate
move
Lock
Unlock
