Fender ACOUSTIC PREVERB - Overview

13
14
1
2
11
8
4 5 6
1. Reverb Footswitch/LED
2. Output Jack
3. Tilt
4. Type Switch
5. Level
6. Damping
7. Time
8. Gain Control/LED
9. Polarity Switch
10. Notch Switch/Control
11. Input Jack
12. Mute Footswitch/LED
13. LED Kill Switch
14. DC Power Connector
3
12
LEDs
9V DC
INPUT
ACOUSTIC PREVERB
GAINTILT
POLNOTCH
TIME
MUTEREVERB
9
7
LEVEL
TYPE
DAMPING
10
