32
Appendices
Appendix 2 MIDI Implementation Chart
NOTES:
The Cyber–Deluxe™ amplifier does not recognize or transmit System
Common messages.
All changes to preset parameters, whether by front panel control,
expression pedal control, SysEx messages, MIDI channel messages, or
continuous controllers, are transmitted via MIDI Out (if a transmit channel is
selected). Another Cyber–Deluxe™ amplifier which is connected and
configured as a receive MIDI device will “mirror” the preset parameter
changes (via continuous controller channels). This process uses SysEx
messages to affect preset parameter changes.
FUNCTION TRANSMITTED RECOGNIZED REMARKS
Basic Default X (disabled) Omni Channel setting changes stored
Channel Changed 1 - 16 1 – 16, Omni in static memory.
Default Mode 3 Mode 2 Receiver Mode is front panel
Mode Messages X X settable to Mode 2 or 4 and
Altered X Mode 2, Mode 4 is stored in static memory.
Note Note Number X X
Number True Voice X X
Velocity Note ON X X
Note OFF X X
After Keys X X
Touch Channel X X
Pitch BenderXX
Control Change O O Assignable Continuous Controller numbers are
1 through 100.
Program Implemented O O All program changes in Bank #00.
Change True # 64(00 – 63) 64(00 – 63) Program changes to program 127 (any bank)
activates/deactivates the Tuner.
System Exclusive O O See Appendix 4,5,6
System Song Position X X
Common Song Select X X
Tune Request X X
System Clock X X
Real Time Commands X X
Local On/Off X X
Auxiliary All Notes Off X X
Messages Active Sensing X X
System Reset X X
GM ON X X
Mode 1: Omni On, Poly Mode 2: Omni On, Mono O: Yes
Mode 3: Omni Off, Poly Mode 4: Omni Off, Mono X: No
