Fender Downtown Express User Manual

2220191817
16
9
21
13 14121110
5
7
1 2 3 4
1. Mute Footswitch & LED
2. Equalizer Footswitch & LED
3. Overdrive Footswitch & LED
4. Compressor Footswitch & LED
5. Master
6. Bass (Equalizer)
7. Middle (Equalizer)
8. Treble(Equalizer)
9. OD/Comp Switch
10. Level (Overdrive)
11. Tone (Overdrive)
12. Drive (Overdrive)
13. Blend (Compressor)
14. Gain (Compressor)
15. Gain Reduction LED
16. Threshold(Compressor)
17. Input Jack
18. Tuner Output Jack
19. Outut Jack
20. XLR Output
21. Ground Lift
22. Signal Path Switch
23. DC Power Connector
24. LED Kill Switch
2423
DOWNTOWN EXPRESS
LEVEL
EQUALIZERMUTE OVERDRIVE COMPRESSOR
BASS TREBLEMIDDLE
DRIVE
EQUALIZER
G.R.
TONE
OVERDRIVE
BLEND THRESHOLD
MASTER
GAIN
COMPRESSOR
OD COMP
COMP OD
SIGNAL PATHXLR OUTPUTINPUT TUNER
OUTPUT
OUTPUT
GROUND
LIFT
9V DC
INPUT
LEDs
86
15

Fender Downtown Express Specifications

General

Type	Bass Multi-Effects Pedal
Bypass Switching	True Bypass
Effects	Compressor
Inputs	1 x 1/4" Instrument
Power Source	9V DC power supply
Controls	Treble, Mid, Bass
Outputs	1 x 1/4" Main Output, 1 x 1/4" Tuner Output
