Fender PASSPORT Schematic Diagram

24
PASSPORT
Wiring Diagram
The following shows the legend of the mating connections
SVC-PD15011+CD SVC-PD15011+LCD
1 MCU RESET 1 MCU RESET
2 3.3V 2 3.3V
3 3.3V 3 3.3V
4 GND 4 GND
5 GND 5 GND
6 LOAD+ 6 LOAD+
78V 78V
8 LOAD- 8 LOAD-
9 LOADER SW3 9 LOADER SW3
10 GND 10 GND
11 LOADER SW2 11 LOADER SW2
12 STBY 12 STBY
13 LOADER SW1 13 LOADER SW1
14 DATA 14 DATA
15 GND 15 GND
16 STBY 16 STBY
17 GND 17 GND
18 ACK 18 ACK
19 GND 19 GND
20 GND 20 GND
SVC-PD25011+CD SVC-PD25011+MIX
1R 1R
2 GND 2 GND
3 GND 3 GND
4L L
SVC-PD25011+DAMP SVC-PD25011+SMPS
1 27V 1 27V
2 GND 2 GND
3 GND 3 GND
4 -27V -27V
SVC-PD25011+CD SVC-PD25011+SMPS
15V 15V
2 GND 2 GND
3 GND 3 GND
48V 48V
SVC-PD25011-MIXER SVC-PD25011+SMPS
1 15V 1 15V
2 GND 2 GND
3 GND 3 GND
4 -15V 4 -15V
SVC-PD25011+DAMP SVC-PD25011+MIXER
1 GND 1 GND
2R+ 2 R+
3R- 3 R-
4L+ 4L+
5L- 5 L-
CN409
CN3
CN4
CN5 CN6
CON801 CN2
J701CN408
CN405 CN11
CN10CON802
