Fender PASSPORT Schematic Diagram

25
PASSPORT
Wiring Diagram
6 GND 6 GND
SVC-PD25011+DAMP SVC-PD25011+MIXER
1 DET-L 1 DET-L
2 DET-R 2 DET-R
3 DET-P 3 DET-P
SVC-PD25011+MIXER SVC-PD25011+DREV
1 15V 1 15V
2 GND 2 GND
3 -15V 3 -15V
4 INPUT 4 INPUT
5 GND 5 GND
6 OUTPUT 6 OUTPUT
SVC-PD25011+DREV SVC-PD25011+SMPS
1 GND 1 GND
28V 28V
SVC-PD25011+MIXER SVC-PD25011+INPUT
1 15V 1 15V
2 -15V 2 -15V
3 LINE1 3 LINE1
4 LINE2 4 LINE2
5 LINE3 5 LINE3
6 LINE4 6 LINE4
7 GND 7 GND
SVC-PD25011+MIXER SVC-PD25011+INPUT
1 GND 1 GND
2 GND 2 GND
3L 3L
4R 4R
5 MAIN-L 5 MAIN-L
6 MAIN-R 6 MAIN-R
7 OUTPUT 7 OUTPUT
8L 8L
9R 9R
10 FOOT SW 10 FOOT SW
SVC-PD25011+MIXER SVC-PD25011+INPUT
1 RTN-R 1 RTN-R
2 GND 2 GND
3 RTN-L 3 RTN-L
4 R OUT 4 R OUT
5 L OUT 5 L OUT
6 DET 6 DET
CON805 CN8
CN9 CN401
CN403 CN7
CN6 CN103
CN4 CN101
CN102CN7
