LEDs
9V DC
INPUT
BYPASS
REFLECTING POOL
TYPE
EXTRA RATE DEPTH
TYPE SUBD QUALITYVARIATION
REVERB DELAY
DELAYTAPREVERB
MIXLEVELDAMP TIME FEEDBACK LEVELDECAY
L/MONO
IN OUT
R L/MONO R
TAP
FS
USB
1
2
6 7
3 4 5 8 9 10 11
19
18
2523222120 24
28
26 27
1. Reverb Footswitch & LED
2. Extra
3. Decay
4. Damp
5. Level (Reverb)
6. Reverb Type Switch
7. Variation Switch
8. Time
9. Feedback
10. Mix
11. Level (Delay)
12. Rate
13. Rate LED Indicator
14. Depth
15. Delay Type Switch
16. Subdivision Switch
17. Quality Switch
18. Delay Footswitch & LED
19. Delay Tap Tempo Footswitch & LED
Delay Controls Rear Panel ControlsReverb Controls
20. L/Mono Input Jack
21. Right Input Jack
22. L/Mono Output Jack
23. Right Output Jack
24. Tap Footswitch Jack
25. USB Jack
26. Bypass Mode Switch
27. LED Kill Switch
28. DC Power Connector
12 13 14 15 16 17
