Fender Reflecting Pool - Reverb Controls; Reverb Bypass Footswitch & LED; Decay; Damp

Reverb Bypass Footswitch & LED
Footswitch bypasses reverb effect. LED Illuminates when reverb is active.
Decay
This control adjusts the reverb decay time, or length of the reverb signal.
Counterclockwise settings produce smaller room and ambient sounds, while
settings closer to fully clockwise can produce the sound of huge spaces.
Damp
Attenuates high frequencies and “darkens” reverb tail.
Level (Reverb)
Controls “wet/dry” reverb signal mix.
Reverb
Type Switch
HALL
1: small hall
2: medium hall
3: large hall
1: small room
2: medium room
3: large room
1: Shimmer
2: Gated/
Reverse
3: Modulated
ROOM
SPECIAL
Variation
Switch
Description
Classic diffuse space with a
sense that walls are far apart.
Smaller, more lively feel
than HALL.
Very large space with some pitch
modulation. Ideal for ambient pads and
swells.
Small-space reverb, plus gated and
reverse reverb. Set EXTRA and LEVEL
control knobs at full clockwise position
for “full-wet” reverse effect.
Classic modern reverb effect with
octave-up pitch shift in loop between
reverb input and output. Successive
octaves are added as reverb decays,
imparting a blooming, atmospheric effect.
Controls amount of regeneration into octave-up reverb effect,
which determines how much of the octave is heard and how
much octaves will “stack.”
Controls reverb tail shape. At full counterclockwise, shape is a
typicaldecaying taper. At noon produces a gated shape; at full
clockwise produces reverse reverb.
Controls reverb modulation depth
(modulation rate fixed at 0.1 Hz).
Controls amount of low-frequency rolloff in reverb decay. Turn
EXTRA knob counter-clockwise for more bass in reverb tail;
clockwise for less (similar to a bass cut).
“Extra” Knob Function
Extra
Modifies an “extra” algorithm-specific parameter. On “Hall” and
“Room”reverb settings it controls “tilt” between high and low
frequency decay times. On Special “Shimmer” setting (see
“Variation Switch” below) it controls regeneration of cascading octaves.
On Special “Gated/Reverse” setting (see “Variation Switch” below) it
controls reverb tail shape, and on Special “Modulated” setting it controls
modulation depth.
Type Switch
Toggle among Hall, Room and Special reverb types
Variation Switch
Toggles among three different variations for each reverb type:
REVERB CONTROLS
