STAGE® 1000/1600
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY above.
Unique Fender® part. Order directly from the Fender® dealer Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
12
PARTS LIST:
TUNER/TIMBRE DISPLAY PCB ASSY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 * CAP AE RDL 22uF 50V 20% C3
1 * LED GREEN T-1 3mm DIFFUSED D45
11 * LED RED LONG LEAD LUMEX D1-4, D6-8, D11, D44, D46 D49
3 * CONTROL SNAPIN 50k B TAPER R134-135 R138
4 * RES CF 1/4W 5% 1Kohm LL R20-23
2 * CABLE JMPR 6 CKT .156 ROUND PW1A PW1B
2 * LED WHT T-1 3mm CLEAR D5, D40
2 * RES CF 1/6W 5% 10k LL R17-18,13
4 * RES CF 1/6W 5% 100k LL R145-148
14 * RES CF 1/6W 5% 240ohm LL R1-7 R40-43 R48-49 R52
2 * RES CF 1/6W 5% 6.8k R8 R12
2 * ENCODER 16-POS 4-BIT GREY CODE (Noble) S4-5
2 * IC 8-BIT SHIFT REG 74AHCT595 (TI) U1-2
4 * LED T-1 3mm DIFFUSED BLUE (SUN LED) D15-18
1 * PCB FAB TUNER/VOICE DISPLAY .
To Next Page
