STAGE® 1000/1600
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY above.
Unique Fender® part. Order directly from the Fender® dealer Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
6
PARTS LIST:
MAIN – PCB ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
REF PCB ASSEMBLY STAGE 1000/1600
1 0027627001 RES FILM 1W 5% 10ohm LL R112
1 0031067001 RES FILM 1W 5% 750ohm LL R158
4 0039209001 RES FILM 1W 5% .22ohm LL R120-123
2 0027628001 RES MOX 2W 5% 47ohm LL R110-111
2 0028021001 RES MOX 2W 5% 470ohm LL R124-125
2 0063741000 **RES MF FUSE 2W 5% 47ohm R155-156
1 0055781001 **RES MF FUSE 2W 5% 82ohm R157
6 0028028000 RES WW BT 5W 10% .47ohm R100-101 R104-105 R108-109
1 0053860000 CAP MPF .1uF 250VAC 20% C114
4 0038699001 CAP CA 100pF 100V LL C7 C32 C41-42
4 0039263001 CAP CA 1000pF 50V LL C3 C18 C22 C30
6 0039259001 CAP CA 220pF 100V LL C33-36 C62-63
4 0038701001 CAP CA 470pF 50V LL C9 C16 C26 C43
2 0039256001 CAP CA 68pF 100V LL C44-45
1 0051457003 CAP CD 100pF 500V 5% C94
10 0051406003 CAP CD 220pF 500V 10% C66-67 C95 C116-118 C123-126
3 0047198003 CAP CR .1uF 50V 20% .1" LS C31 C127-128
16 0034788003 CAP CR .1uF 50V 20% .2" LS C37-38 C57-58 C68-69 C71-72 C79-80 C104-
109
55 0006260001 DIODE 1N4448 SIGNAL LL D1-10 D13-18 D21-24 D27 D36-39 D41-44 D58-
59 D63 D65 D67 D70-72 D74-77 D79-84 D93-94
D97
9 0064089001 DIODE 1N4003 D25-26 D40 D46-47 D48-51
4 0029045000 DIODE 6A 400V 6A4 LEAD FORMED D54-57
2 0054210001 DIODE BAT85 D19-20
1 0031635001 DIODE ZEN 1N5240B 10V 5% LL D64
1 0031019001 DIODE ZEN 1N5245B 15V 5% LL D66
2 0036178000 SPACER LED .5x.1 BRN @D45,73
3 0027329001 DIODE ZEN 1N5228B 3.9V 5% LL D60-62
2 0028119000 DIODE ZEN 1N5353B 16V 5W 5% D52-53
4 0028458003 CAP AE RDL 1uF 50V 20% C14 C28 C75 C77
7 0028474003 CAP AE RDL 100uF 25V 20% C50 C55-56 C84-85 C100-101
5 0028459003 CAP AE RDL 2.2uF 50V 20% C6 C17 C29 C53 C70
9 0028467003 CAP AE RDL 22uF 50V 20% C8 C10 C19 C39-40 C46 C81 C110-111
2 0028031000 CAP AE RDL 3300uF 63V +100%-20% C86-87
1 0033606003 CAP AE RDL .47uF 50V 20% C47
3 0028471003 CAP AE RDL 47uF 50V 20% C51 C102-103
3 0055780000 CAP AE RDL 1000uF 35V 105C 20% C78 C82-83
16 0025802000 FASTON TAB, .250" P1-16
1 0020775000x2 **FUSE CLIP PCB 5mm F1
1 0027872001 RES CF 1/2W 5% 1.2k LL R191
1 0031767001 RES CF 1/2W 5% 15ohm LL R126
1 0026549001 RES CF 1/2W 5% 1.5k LL R192
1 0027416000 HDR .1 CTR 8 CKT SQ PIN P20
2 0057350000 HDR .1 CTR 8x2 CKT SQ PIN P19 P21
3 0051658000 JACK MONO R/A J2-3 J6
2 0053450000 JACK STEREO R/A J4 J7
1 0059889000 JACK STEREO R/A w/METAL BUSH J1
REF JUMPER WIRE 22GA W4-14
1 0027387000 INDUCTOR AIR CORE RDL 2.5uH L1
1 0047179000 LED AMBER D45
1 0049948000 LED RED LONG LEAD LUMEX D73
