STAGE® 1000/1600
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY above.
Unique Fender® part. Order directly from the Fender® dealer Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
7
PARTS LIST:
MAIN – PCB ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
2 0049948000 LED RED LONG LEAD LUMEX D11-12
2 0027255003 CAP MPF .001uF 100V 10% C119 C121
2 0027264003 CAP MPF .01uF 100V 10% C54 C122
1 0027278003 CAP MPF .1uF 63V 10% C25
2 0027257003 CAP MPF .0022uF 100V 10% C59-60
1 0027267003 CAP MPF .022uF 100V 10% C21
4 0027281003 CAP MPF .22uF 63V 10% C5 C89-91
2 0027259003 CAP MPF .0033uF 100V 10% C23 C48
1 0027270003 CAP MPF .033uF 100V 10% C12
3 0027261003 CAP MPF .0047uF 100V 10% C1-2 C24
11 0027272003 CAP MPF .047uF 63V 10% C11 C13 C20 C64-65 C76 C92 C96-99
6 0027286003 CAP MPF .47uF 63V 10% C4 C15 C27 C52 C88 C93
1 0027275003 CAP MPF .068uF 100V 10% C49
2 0052003003 CAP MPF .1uF 250V 10% C112-113
1 0026411000 THERMISTOR 2.5 ohm 8A C30-19 RT1
3 0027947000 CONTROL SNAPIN 100k 30C TAPER R24 R42 R48
1 0027949000 CONTROL SNAPIN 250k 30C TAPER R45
1 0054390000 CONTROL SNAPIN 5k 15A TAPER R11
4 0027940000 CONTROL SNAPIN 50k 15A TAPER R10 R16 R34 R52
2 0027941000 CONTROL SNAPIN 50k B TAPER R9 R38
1 0051418003 THERMAL SENSOR PTC 100 DEG C RT2
1 0024952001 RES CF 1/4W 5% 100ohm LL R53
12 0024965001 RES CF 1/4W 5% 1k LL R20 R35-36 R85 R95-96 R118-119 R127 R131
R151 R202
22 0024981001 RES CF 1/4W 5% 10k LL R27 R29 R49-51 R62-63 R97 R115-116 R129
R136 R139 R143-144 R183 R193 R209 R211-
212 R214-215
14 0024997001 RES CF 1/4W 5% 100k LL R18-19 R41 R83 R86 R128 R130 R165 R172
R182 R188-190 R200
10 0025069001 RES CF 1/4W 5% 1M LL R149 R152 R166 R170 R173 R177 R186-187
R194 R201
1 0024954001 RES CF 1/4W 5% 150ohm LL R81
10 0024969001 RES CF 1/4W 5% 1.5k LL R47 R98-99 R102-103 R106-107 R132 R162
R181
2 0024985001 RES CF 1/4W 5% 15k LL R1 R6
1 0029453001 RES CF 1/4W 5% 1.6k LL R208
2 0025058001 RES CF 1/4W 5% 180k LL R13 R55
4 0024956001 RES CF 1/4W 5% 220ohm LL R87 R94 R198-199
6 0024971001 RES CF 1/4W 5% 2.2k LL R17 R66-67 R82 R84 R117
7 0024987001 RES CF 1/4W 5% 22k LL R8 R12 R21-22 R54 R150 R153
3 0025059001 RES CF 1/4W 5% 220k LL R15 R31 R180
8 0024988001 RES CF 1/4W 5% 27k LL R64-65 R72-75 R113-114
1 0029604001 RES CF 1/4W 5% 300ohm LL R80
1 0028865001 RES CF 1/4W 5% 30k LL R26
4 0024973001 RES CF 1/4W 5% 3.3k LL R76 R88 R93 R133
4 0024989001 RES CF 1/4W 5% 33k LL R40 R43 R46 R176
2 0025061001 RES CF 1/4W 5% 330k LL R175 R184
4 0024947001 RES CF 1/4W 5% 47ohm LL R7 R196-197 R207
1 0024977001 RES CF 1/4W 5% 4.7k LL R77
7 0024993001 RES CF 1/4W 5% 47k LL R32-33 R37 R39 R78-79 R195
5 0025065001 RES CF 1/4W 5% 470k LL R30 R159 R169 R171 R174
5 0028034001 RES CF 1/4W 5% 5.1k LL R4 R68-71
2 0028018001 RES CF 1/4W 5% 510k LL R2-3
