STAGE® 1000/1600
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY above.
Unique Fender® part. Order directly from the Fender® dealer Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
9
PARTS LIST: uDSP – PCB ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
14
*
CAP 0805 CER .01uF 25V 5%
10
*
CAP 0805 CER .1uF 25V 5%
2
*
CAP 0805 CER 22pF 25V 5%
2
*
CAP 0805 CER 750Pf 25v 5%
3
*
CAP 3528 TAN 4.7uF 16V 20%
6
*
CAP 3528 TAN 10uF 16V 20%
5
*
DIODE SMT 1N4448 SIGNAL
2
*
HDR .1 CTR 8x2 CKT SQ PIN
4
*
RES 0805 MF 1/10W 5% 0ohm
2
*
RES 0805 MF 1/10W 5% 100ohm
4
*
RES 0805 MF 1/10W 5% 750ohm
4
*
RES 0805 MF 1/10W 5% 1k
1
*
RES 0805 MF 1/10W 5% 2k
1
*
RES 0805 MF 1/10W 5% 3.3k
2
*
RES 0805 MF 1/10W 5% 4.7k
1
*
RES 0805 MF 1/10W 5% 15k
1
*
RES 0805 MF 1/10W 5% 47k
1
*
IC SMT SOCKET PLCC 44-TT
1
*
IC SMT TLC549 AD
1
*
IC SMT SRAM 64Kx16
1
*
IC SMT COUNTER 74LV4040
1
*
IC SMT HEX SCHMITT-T INV 74HC14
1
*
IC SMT VREG +3.3V LM1117
1
*
IC SMT CODEC TLC320AD77C
1
*
IC SMT DSP TMS320VC5402PGE
1
*
IC SMT VREG +1.8V 150mA TPS76318
1
*
IC SMT RESET 5V MC34064D-5
1
*
XTAL 20MHz HC49SD
PARTS LIST: CHASSIS ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
REF CHASSIS ASSY STAGE 1000
REF CHASSIS ASSY STAGE 1600
REF LABEL GROUNDING SEMKO
2 0025936000 STANDOFF NYL PCB SNAP 3/8" NAT
7 0028500000 SCRW TF 8-32x3/4 HWH SLTD Z1 @ HEATSINK
1 0028564000 END BELL XFMR 185 Series @ XFMR
4 0028591000 NUT ACORN 8-32 @ XFMR
2 0028937000 SCRW TF 6-32x5/8 PHP ZI TAPTYT @ STNDOFF
4 0030007000 WSHR LCK INTL 8x.330x.02 ZI @ XFMR
1 0016352000 NUT HWX 3/8-32X3/32 TK NI(049) @FP JACK
1 0038900000 SCRW TF 6-32X1/4 PHP ZI @ GND LUG
1 0039129000 **XFMR PWR STAGE 120V
1 0039203000 HEATSINK BAR STAGE 112SE
1 0039236000 **SWITCH ROCKER DPST PSEUDO-IEC 100-120V
2 0051155000 SCRW SMB #4X3/8 PHP BLX @ XLR JACK
4 0051404000 STANDOFF NYLON BLK .375 @ uDSP ASSY
5 0055838000 NUT PLASTIC BLK REAN JACK @ BP JACKS
1 0031153000 WASHER FLAT 3/8 x .164 NI (049) @FP JACK
1 0053884000 FUSE QA 20mmX5mm 125V 4A UL/CSA 100-120V
11 0053986000 KNOB ROTARY SS W/CHR INSERT @ ANALOGCONTROLS
REF WIRE SET CHS STAGE 100/160 DOM
