STAGE® 1000/1600
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY above.
Unique Fender® part. Order directly from the Fender® dealer Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
11
PARTS LIST: END ITEM ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0038566000 CABLE ASSY SPKR RT ANG 13-1/2" CONNECT SPKR
1 0063698000 CAB ASSY STAGE 1000
1 0063699000 CAB ASSY STAGE 1600
1 0047248000 CORD PWR W/IEC CONN DOM
REF FOAM STYRENE TOP PKG.
REF FOAM STYRENE BOTTOM PKG.
REF TAG WARRANTY 5 YR FENDER NEW HANG ON KNOBS
REF STICKER, BUMPER FEND 1946 HANG ON KNOBS
REF REGISTRATION CARD
1 0054420000 SPEAKER 12"8 OHM G12T-100 1887 STAGE1000/1600
REF CORROSEAL 50# (12" X 250' ROLL) @ PWR CORD
1 0062191000 FTSW ASSY 4 BTN STAGE 1000/1600 :
1 0062181000 CHS ASSY STAGE 1000 120V
1 0062194000 MANUAL OWNERS STAGE 1000/1600 LIT. PACK
1 0063653000 BADGE STAGE 1000
REF POP Stage 1000/1600
1 9903320000 BAG POLY ZIP 10X13 2M @ LIT. PACK
REF CHASSIS ASSY STAGE 1600 120V
1 0063652000 BADGE STAGE 1600
PARTS LIST: FOOTSWITCH ASSY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
0062191000 FTSW ASSY 4BTN STAGE 1000/1600
1 0028895000 CABLE ASSY FTSW RT ANG 12’
1
*
HOUSING FTSW 4 BUTTON
1
*
HSG END CUP LEFT FTSW
1
*
HSG END CUP RIGHT FTSW
1
*
PLATE FTSW 4 BTN STAGE 1000/1600
8
*
SCRW SMB 6x3/8 PH PHS BLX @ END CUPS
1
*
NUT HEX 12mmx1mm NI @ JACK
4
*
WSHR NYL .485x.775x.150 TK @ SWITCHES
1
*
PCB FAB FTSW 4 BTN STAGE DSP
5
*
DIODE 1N4448 SIGNAL D1, D2, D6, D10, D11
2
*
DIODE ZEN 1N5228B 3.9V 5% D7, D12
1
*
DIODE ZEN 1N5223B 2.7V 5% D4
1
*
JACK PCB MONO CA J1
1
*
LED BI-COLOR 5mmx5mm D9
3
*
LED RED 5mmx5mm SLB-55VR3 D3, D5, D8
1
*
RES CF 1/4W 5% 75 ohm R1
3
*
SPACER RND NYL .147x.250x.780 @ D3, D5, D8
1
*
SPACER RND NYL .147x.250x.680 @ D9
4
*
SWITCH PUSH SPDT S1-S4
PARTS LIST: TUNER/TIMBRE DISPLAY PCB ASSY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
0055367000 PCB ASSY TUNER/TIMBRE DISPLAY
4 * CAP CR .1uF 50V 20% .1" LS C1,2,4,5
8 * DIODE 1N4448 SIGNAL LL D28-35
1 * CABLE, RIBBON 2CKT X 10" (KONEX) P2
9 * Jumper W1-9
