STAGE® 1000/1600
(This is the model name for warranty claims)
3
SPECIFICATIONS
Model Name: Stage 1000 Stage 1600
Release Number: PR 577 PR 572
(Not model numbers)
Part Numbers (120V, 60Hz) US: 2267000030 2268000030
(110V, 60Hz) TW: 2267001030 2268001030
(240V, 50Hz) AUS: 2267003030 2268003030
(230V, 50Hz) UK: 2267004030 2268004030
(230V, 50Hz) ARG: 2267005030 2268005030
(230V, 50Hz) EUR: 2267006030 2268006030
(100V, 50/60Hz) JPN: 2267007030 2268007030
(220V, 60Hz) ROK: 2267009030 2268009030
(For all Models)
Power Requirement: 400W
Power Output: 100W RMS into 8 ohms @ 5%THD
160W RMS into 4 ohms @ 5%THD
Power Amp Sensitivity: 620mV for 100W into 8 ohms @ 5%THD
810mV for 160W into 4 ohms @ 5%THD
Impedances Input (Pre-Amp): 1M ohms
Pre Amp Out: 1k ohms
Pwr Amp In: 10k ohms
Speaker Complement: One (1) 12", 8 ohm, Two (2) 12”, 8 ohm, -NA-
Celestion G12T-100 Celestion G12T-100
(P/N 0054420000) (P/N 0054420000)
Dimensions Height: 17.5 in (45 cm) 18.5 in (47 cm) 8.5 in (22 cm)
Width: 22.4 in (57 cm) 26.1 in (66 cm) 22.4 in (57 cm)
Depth: 10.2 in (26 cm) 10.3 in (26 cm) 9.5 in (24 cm)
Weight: 42 lbs (19.1 kg) 53 lbs (24.1 kg) 24 lbs (10.9 kg)
Product specifications are subject to change without notice
