STAGE® 1000/1600
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY above.
Unique Fender® part. Order directly from the Fender® dealer Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
8
PARTS LIST:
MAIN – PCB ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0024978001 RES CF 1/4W 5% 5.6k LL R210
4 0024979001 RES CF 1/4W 5% 6.8k LL R5 R14 R25 R28
1 0024995001 RES CF 1/4W 5% 68k LL R44
1 0024980001 RES CF 1/4W 5% 8.2k LL R23
1 0025068001 RES CF 1/4W 5% 820k LL R168
1 0015582001 RES MF 1/4W 1% 10.0k LL R179
1 0025816001 RES MF 1/4W 1% 20.0k LL R178
2 0034781001 RES MF 1/4W 1% 2.10k LL R89 R92
1 0016979001 RES MF 1/4W 1% 215k LL R163
5 0027632001 RES MF 1/4W 1% 2.43k LL R140-142, (R90,91 WHEN Q14-19 MADE BY
ONSEMI)
2 0025810001 RES MF 1/4W 1% 2.49k LL R90-91 WHEN Q14-19 MADE BY ST
1 0016971001 RES MF 1/4W 1% 33.2k LL R160
1 0017191001 RES MF 1/4W 1% 36.5k LL R167
2 0017372001 RES MF 1/4W 1% 51.1k LL R161 R164
4 0016739003 XSTR NPN 2N4401 TO-92 Q12 Q26 Q29 Q31
8 0016742003 XSTR PNP 2N4403 TO-92 Q13 Q21 Q23-25 Q27-28 Q30
1 0051447003 XSTR PNP 2SB1236 Q11
1 0051448003 XSTR NPN 2SD1857 Q10
13 0014689003 XSTR N-CH JFET J111 TO-92 Q1-9 Q20 Q22 Q32-33
3 0028114000 XSTR NPN TIP142 TO-218AC Q14 Q16 Q18
3 0028115000 XSTR PNP TIP147 TO-218AC Q15 Q17 Q19
1 0048914000 CABLE RIBBON 8 CKT 7" PW20
1 0051416003 CAP SF .1uF 100V 10% C61
2 0028091000 SWITCH PUSH SLFLK SHORT STROKE S1-2
1 0028120000 IC 4053B TPL 2 CHAN ANLG SW U10
6 0031611000 IC OP-AMP DUAL PC4560 U4-9
1 0041812000 IC REGULATOR +5V MC7805CT U11
1 0054427000 IC EPROM 8K U12
1 0055985000 IC 8-BIT SHIFT REG 74HC166 U13
2 0041261000 IC VOLT REF LM4040DIZ-10.0 D68-69
3 0016795000 IC OP-AMP DUAL TL072 U1-3
1 0054261000 XLR CONNECTOR MALE RT ANGLE J5
1 0025796000 HEATSINK TO-220 @ REGULATOR
6 0032908000 SCRW TF 6-32x3/8 PHP ZI @ HEATSINK PLATE
6 0027638000 SCRW TF 4-40x3/8 HWHS ZI .1" HD @ PWR XSTRS
6 0028169000 WSHR SHLDR NYL 5/32x1/4 @ PWR XSTRS
6 0040903000 INSULATOR MICA TO-218 @ PWR XSTRS
1 0031077000 SCRW TF 4-40x1/4 H @7805
1 0054259000 HEATSINK PLATE STAGE 100/160
REF WIRE SET PCB STAGE 100/160
2 0048451000 BUTTON PUSH OFF WHITE
REF **PCB FAB STAGE 1000/1600
PARTS LIST:
uDSP – PCB ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0063680000
**PCB ASSY uDSP STAGE 1000/1600
w/ EPROM
REF 0057283000 SVC DIAG COMB MICRO DSP
1
*
IC ROM STAGE 1000/1600 V1.00
1
*
PCB Fab u-DSP
2
*
CAP 0805 CER .001uF 25V 5%
To Next Page
