Fender Tone Master PRO - Specifications

TYPE PR 5642
POWER REQUIREMENTS 40W
INPUT VOLTAGE 100V-240V 50/60Hz
ANALOG INPUTS INSTRUMENT 1/4” phone jack
IMPEDANCE 1MΩ/330kΩ/22kΩ configurable, unbalanced
MAX INPUT LEVEL 11.2dBu (17.2dBu with input pad on)
MIC/LINE Combination XLR 1/4“ TRS phone jack
MIC IMPEDANCE (XLR) 1.8kΩ balanced
MAX MIC INPUT LEVEL 15.7dBu
MIC PHANTOM POWER +48V on/off (XLR only)
LINE IMPEDANCE (1/4”) 1MΩ balanced 1MΩ unbalanced
MAX LINE INPUT LEVEL 20.1dBu balanced 15.3dBu unbalanced
FX LOOP 3/4 RETURNS 1/4“ TRS phone jacks
IMPEDANCE 10kΩ balanced 10kΩ unbalanced
MAX INPUT LEVEL 15.8dBu line 10.9dBu instrument
AUX IN 3.5mm stereo phone jack
IMPEDANCE 10kΩ unbalanced
MAX INPUT LEVEL 9.8dBu
ANALOG OUTPUTS OUTPUT 1 L/R XLR 1/4” TRS phone jacks
IMPEDANCE LINE LEVEL 200Ω balanced 200Ω unbalanced
IMPEDANCE INSTRUMENT LEVEL 290Ω balanced 400Ω unbalanced
MAX OUTPUT LEVEL BALANCED 23.8dBu line 14.1dBu instrument
MAX OUTPUT LEVEL UNBALANCED 18.0dBu line 11.2dBu instrument
OUTPUT 2 L/R 1/4” TRS phone jacks
IMPEDANCE 170Ω balanced 170Ω unbalanced
MAX OUTPUT LEVEL 15.8dBu line 10.9dBu instrument
FX LOOP 3/4 SENDS 1/4“ TRS phone jacks
IMPEDANCE 170Ω balanced 170Ω unbalanced
MAX OUTPUT LEVEL 15.8dBu line 10.9dBu instrument
HEADPHONES 1/4“ stereo phone jack
MIN LOAD IMPEDANCE 16Ω x2
MAX OUTPUT POWER 110mW x2
A/D, D/A CONVERSION BIT DEPTH 32 bits
SAMPLE RATE 44.1kHz
DYNAMIC RANGE 117dB ADC 112dB DAC
FREQUENCY RESPONSE 20Hz-20kHz +0.1/-0.7dB
DIGITAL AUDIO I/O CONNECTOR USB-C
USB AUDIO CLOCK 44.1kHz, 48kHz, 88.2kHz, 96kHz (DAW selectable)
EXP 1/2 PEDAL INTERFACE CONNECTOR 1/4” TRS phone jacks
FORMAT 1kΩ-500kΩ linear taper, signal (tip) power (ring)
POLARITY Normal or reverse (selectable)
TOE SWITCH CONNECTOR 1/4” TS phone jack
FORMAT Latching,or momentary (selectable)
EXTERNAL AMP CONTROL CONNECTOR 1/4” TRS phone jack
FORMAT Two latching contact closures (tip-sleeve, ring-sleeve)
POLARITY Normal or reverse (selectable)
MIDI INTERFACE IN-OUT/THRU/MERGE 5-pin DIN connectors
DIMENSIONS/WEIGHT 14.6”/371mm 10.3”/261.4mm 3.8”/96.4mm 8.8 lbs./4.0kg
