Ferguson F1915LVD - Composite Video Output (RCA); SCART Connection

21
ToAUDIO/VIDEOOUTjacks
ToAUDIO/
VIDEOINjacks
(AV IN 1)
CONNECTING TO DEVICES WITH A COMPOSITE (YELLOW RCA-TYPE) VIDEO OUTPUT
ToconnecttoA/VdevicessuchasaVCR,camcorderorvideogamesystem.
- Connect to a VCR / Video Game System / Camcorder
Connect theAUDIO /VIDEO cable (not included) as
shown.
Makesureyouconnectthecablefromtheotherequipment
(AUDIO and VIDEO OUT) to this unit (AUDIO and
VIDEO IN).PresstheFUNCTIONorAVbuttontoselect
AV1mode.
Note:
Pleaserefertotheusermanualfortheotherequipmentfor
moreinformation.
CONNECTIONS
CONNECTING TO SOURCES WITH SCART
DeviceswithRGBoutputmustbeconnectedto
theSCARTinput:
Connects the SCART from the source to the
correspondingSCARTonthisunit(SCARTcable
notincluded)asshown.
Make sure you connect both to SCART to
SCART.
Tooperatetheconnecteddeviceandplaythe
source,rstpresstheFUNCTIONorAV button
toselecttheAV2/SCARTmode.
COMMON INTERFACE
ThereisaCIslotattopcenterofthecabinetwhichallowsyoutoinsertaCAM(ConditionalAccess
Module)withanappropriateviewingcardforsomesubscriptionTVservices..
Youneedtosubscribetoapaychannelcompanywhoadministerthepaymentsandviewingcard
distributionfortheseservices.
FullyinserttheCAM(ConditionalAccessModule)intotheCI(CommonInterface)slotonthetopof
theunitwiththeserviceprovider’slabelfacingbackward.
Important notes:
•SwitchofftheTVandunplugfromtheACpowermainsbeforeinsertorremovetheCAM.
•TheCAMshouldbecorrectlyinserted,itisimpossibletoinsertfullyifreversed.TheCAMorthe
TV terminal may be damaged if the CAM is forcefully inserted.
•SomeCAMsmayrequiresettingup.Refertothemoduleinstructionmanualfordetailsofthe
settings.
•Ifyourviewingcardsubscriptionisnotvalidforthereceivedserviceyouwillseeamessagesuch
as ‘SCRAMBLED PROGRAM’...’You are not entitled to watch this program’.
COMMON INTERFACE
Thicker casing
Service provider’s label and gold contacts
of viewing card face backwards.
TV
AERIAL
SCART
CABLE
If your VCR permits, then connect your
antenna to your VCR and VCR RF to your TV
