INSTALLATION
INSTALLING / REMOVING THE STAND
WARNING:TheLCDDisplayisveryfragile,andmustbeprotectedatalltimeswheninstalling/
removingthestand.Besurethatnohardorsharpobject,oranythingthatcouldscratchordamage
theLCDdisplay,comesintocontactwithit.DoNOTputpressureonthefrontoftheunitatanytime
becausethescreencouldcrack.
1.Disconnectanycablesorcordsconnectedtotheunit.
2.Laytheunitdownonaatsurface,sothebackisfacingup,makingsuretoplaceasoftcushioned
material(suchasapilloworthickpieceoffoam)beneaththescreen.
3.Install/removethetwoscrewsandtheninstall/removetheSTANDto/fromtheTV.
MOUNTING ON THE WALL
ThisunitisVESA-compliant,andisdesignedtobewall-mountedwithaVESA-compliant75mmx
75mmmountingkitdesignedforat-panelTVs(soldseparately).Mountthisunitaccordingtothe
directionsincludedwiththemountingkit.
Note:
Removethestandbeforemountingtheunitonthewall.
IMPORTANT
Screws must not project more than 8mm into the TV or damage may occur. For secure fixing make
sure at least 4mm of the screw thread is engaged.
75mm
75mm
