Product: Ferm band saw
Type BZ-110, Art.nr. 330742
Ferm, Genemuiden, The Netherlands.
Sound pressure level 85 dB(A)
Sound power level 95 dB(A) LWA
Vibration (-aw) 5 m/s2
SERIAL NUMBER
The serial number on the machine consists of the follo-
wing elements.
Serial nr.
CAREFULLY READ THE INSTRUCTIONS
BEFORE YOU USE THE BAND SAW!
1. FEATURES
Special designed horizontal and vertical band saw. Offers
three speeds for cutting metal, plastic or wood. Shuts off
automatically when material is cit. With scale for the mi-
tering vice. Low noise while operating, quick and easy
moving.
2. SPECIAL SAFETY INSTRUCTIONS
BEFORE USING THE MACHINE:
1. Check the following points.
- do the voltage of the appliance correspond with
the mains voltage, appliances for a mains voltage of
230 V can also be connected at a mains voltage of
220 V;
- are the mains lead and the mains plug in a good con-
dition: solid, without any loose ends or damage;
2. Avoid using long extension cables.
GROUNDING
This tool is equipped with an electric cord having an
equipment grounding conductor and a grounding plug.
The plug must be plugged into a matching, outlet that is
properly installed and grounded in accordance with all lo-
cal codes and ordinances.
SWITCH OFF THE MACHINE IN CASE OF:
1. The machine is overheated.
2. Defective mains plug, mains lead or damage to the
mains lead.
3. Defective switch.
4. Smoke or bad smell caused by scorched insulation.
3. ADJUSTMENT
BLADE GUIDE BEARING ADJUSTMENT.
This is the most important adjustment on your saw. It is
impossible to get satisfactory work from your saw if the
blade guides are not properly adjusted. The blade guide
bearings for your band saw are adjusted and power tes-
ted with several testcuts before leaving the factory to ins-
ure proper setting. The need for adjustment should rare-
ly occur when the saw is used properly. If the guides do
get out of adjustment, it is ex-tremely important to read-
just immediately. If proper adjustment is not maintained,
the blade will not cut straight and if the situation is not
corrected, it willcause blade damage. Because guide ad-
justment is a critical factor in the performance of your
saw, it is always best to try a new blade to see if this will
correct poor cutting before beginning to adjust the be-
arings. If a blade becomes dull on one side sooner than the
other, for example, it will begin cutting crooked. A simple
blade change should correct this problem the more diffi-
cult guide adjustment will not.
If a new blade does not correct the problem, check the
blade guides for proper spacing. There should be 0,001”
clearance between the 0,025” thickness blade and guide
bearings. To obtain this clearance adjust as follows:
1. The inner guide bearing is fixed and cannot be adjus-
ted.
2. The outer guide bearing is mounted to an excentric
bushing and can be adjusted.
3. Loosen the nut while holding the bolt with an Allen
wrench.
4. Position the excentric by turning the bolt to the desi-
red position of clearance.
5. Tighten the nut.
6. Adjust the second blade guide bearing in the same
manner.
7. The back edge of the blade should just touch the lip of
the blade guide bearing.
ORDER NUMBER/YEAR OF CONSTRUCTION
Ferm 27
AVAILABLE SPARE PARTS FOR BZ-110
REF.NR. DESCRIPTION FERM NR.
4 STAND, RIGHT SIDE 400118
13 STAND, LEFT SIDE 400119
23 PUSH BUTTON SWITCH 400128
28 HAND WHEEL 400101
33 VICE NUT 400102
37 CASTING BASE 400117
40 CONDENSOR (MOTOR) 309510
47 SPRING 400103
56 BRACKET LOCK, LEFT 400105
57 BLADE GUIDE BRACKET, LEFT 400104
61 BALL BEARING 806000
62 GUIDE PIVOT 400125
63 BEARING SHAFT PIN 400127
64 BLADE SEAT 400124
65 BLADE GUIDE BRACKET, RIGHT 400123
69 BALL BEARING 800608
79 TENSION KNOB 400106
81 BODY FRAME 400121
85 MOTOR 400107
86 MOTOR PULLEY 400122
87 BALL BEARING 806202
89 OIL SEAL 400109
91 TRANSMISSION GEAR 400110
94 WORM GEAR 400111
103 BLOCK BLADE TENSION 400112
107 BLADE SHEEL SHAFT 400129
111 PULLEY CASE LOWER 400114
112 V-BELT 800130
113 SAW BLADE (ART.NR. 330743) 400116
