Ferno Pegasus - Technical Data

FERNO/MAN/01/18/159/UK 19 Pegasus Trolley
7. Technical Data
Product Name
Pegasus Trolley
Overall Length
1950 mm
Folded Length (Foot End Only)
Folded Length (Head End Only)
Minimum Folded Length (Both Ends)
1730 mm
1650 mm
1450 mm
Overall Width
570 mm
Maximum Height (excluding
mattress)
880 mm
Minimum Height
460 mm
Weight
(Including Mattress, head pad &
restraints)
76.17 kg
Max SWL lowest Position
Max SWL Elevated
300 kg
200kg
Construction Materials
Aluminium Tubing
Aluminium Castings
Plastic Injection Mouldings
IMPORTANT NOTE
The ambulance vehicle must be fitted with a ramp or tail lift to assist trolley
loading. Contact our Technical Sales Department on 01274 851999 for
further details.
The CE mark on this product demonstrates conformity with the
requirements of the EC Directive 93/42/EEC for Medical Devices.
