FERNO/MAN/01/18/159/UK 7 Pegasus Trolley
Unloading the trolley from a vehicle fitted with a tail lift
1. Make sure that the patient is disconnected from any vehicle mounted apparatus
or instrumentation.
2. Operation by a minimum of two operators at all times.
3. Disengage the trolley from the two part locking device by depressing the foot
pedal (manual lock), or pressing the green button (electric lock) and roll the trolley
to the rear of the ambulance compartment.
4. Guide the trolley onto the tail lift and out of the vehicle.
Loading the trolley into a vehicle fitted with a tail lift
1. Make sure that the patient is secure at all times whilst on the trolley.
2. The trolley is loaded with the patient's head towards the front of the ambulance.
3. Ensure that the trolley is in its lowest position and there are no trailing straps,
blankets etc.
4. IMPORTANT: BEFORE LOADING ONTO THE TAIL LIFT, FOLD THE HEAD
END PUSH/PULL HANDLE AND ROTATE UNDER THE TROLLEY TOP UNTIL
IT IS SECURED IN THE RETAINING CLIPS AS DAMAGE TO THE HANDLE
WILL OCCUR IF IT IS INCORRECTLY STOWED. NEVER ROTATE THE
PUSH/PULL HANDLE OVER THE TOP OF THE TROLLEY AS DAMAGE
COULD OCCUR WHEN THE BACKREST IS LOWERED.
5. Guide the trolley on to the tail lift, head end first.
6. Operate the tail lift as per manufacturer’s instructions.
IMPORTANT NOTE
Ensure the trolley is secure at all times when on board the tail lift
