POWERFlexx
™
© Ferno-Washington, Inc. 234-3310-01 May 2005 21
6.6 Adjustable Foot-End Lift Bar
The foot-end lift bar (and control panel) can be adjusted
up or down to suit the operator’s height (Figure 23).
The multi-position hinge locks at increments of
approximately 10°. These positions allow operators of
different heights to use good lifting mechanics to grasp
the frame and use the touch pad controls.
To adjust the foot-end lift bar, press the two hinge
buttons at the same time to unlock the hinges (Figure
24), then rotate the lift bar to a new locking position.
Verify that the lift bar is locked before lifting the cot.
Cot Features
Figure 24 - Adjusting the Foot-End Hinges
Figure 23 - Foot-End Lift Bar Positions
