Safety information/Technical Data
1. Location of accident
2. Type of accident
3. Number of injured people
4. Type of injuries
Store all safety notices and instructions for the future.
6.9 Residual risks
m DANGER
RISK OF INJURY !
Contact with the saw chain can lead to fatal cuts.
Never touch the saw chain with your hands while it is running.
RISK OF KICK-BACK !
Kick-back can lead to fatal cuts.
DANGER OF BURNING !
The chain and guide bar heat up during operation.
7. Technical data
Machine without guide bar L x W x H 375 x 185 x 190 mm
Weight without guide bar and saw chain and
empty tank
5.1 kg
Weight with guide bar and saw chain and
empty tank
6.9 kg
Cutting Length 47 cm
Guide bar length 508 mm
Automatic chain oiling yes
Saw chain Oil Special Saw chain oil
Saw chain oil tank capacity 260 cm
3
Saw chain division 0.325"/ 8,255 mm
Drive link thickness 0,058"/ 1.47 mm
Saw chain type 325.058-76
Number of tooth drive sprocket 7
