Assembly instruction
Installing the blow and vacuum tubes
1
2
4
3
1
5
1. Push the top vacuum tube
2
into the large opening on the motor housing
1
until it audibly snaps into place.
2. Push the bottom vacuum tube
3
into the open end of the top vacuum tube
until it audibly snaps into place.
3. Push the top blow tube
4
into the small opening on the motor housing until it
audibly snaps into place.
4. Push the bottom blow tube
5
into the open end of the top blow tube until it
audibly snaps into place.
