FERREX GLB3300A - Attaching Collecting Bag

2
12
13
13
6
1. Using a Philips screwdriver PH1
12
, screw the screws
6
into the illustrated
positions in the clockwise direction.
Screw in an additional screw on the opposite side of the motor housing.
The blow/vacuum tubes are installed.
Attaching the collecting bag
1. Push the connecting piece of the
collecting bag
7
into the bottom
opening of the motor housing
1
until it audibly snaps into place.
2. Attach the snap hook of the collecting
bag
7
to the eyelet on the bottom
blow tube
5
.
The collecting bag is attached.
3
7
1 5
Assembly instruction
