Attaching the extra handle
1. Attach the extra handle
10
to the
mount for the extra handle
13
with
the bulge pointing down.
The teeth on the mount and on the
extra handle must engage.
2. Push the screw for the extra handle
9
through the hole in the mount and
in the extra handle.
3. Screw the star grip nut
8
clockwise
onto the thread of the screw and
tighten it.
Attaching the shoulder strap
- Connect the clip of the shoulder strap
11
with the attachment point for the
shoulder strap
14
.
Operation
CAUTION!
Risk of injury!
A damaged device or damaged accessories can lead to injuries.
- Check the device and the accessories (see section "Testing").
This chapter describes how to operate the device. The following instructions for use
serve for your own safety and for successful, safe use of the device.
4
10
13
8
9
5
11
14
Assembly instruction
19
