FERREX GLB3300A - Adjusting Extra Handle; Setting Operating Mode

Adjusting the extra handle
Adjust the extra handle
10
to obtain the optimum working position. Always make
sure that the teeth on the extra handle and on the mount
13
engage.
1. Undo the star grip nut
8
.
2. Set the desired position of the extra handle.
3. Tighten the star grip nut again.
Setting the operating mode
Blow function: use this function to blow away dirt outdoors.
Vacuum function: use this function to vacuum up dirt outdoors.
- Set the blow/vacuum selection lever
15
to vacuum.
The vacuum function is active.
-
Set the blow/vacuum selection lever
15
to blow.
The blow function is active.
8
15
9
15
Operation
20
