36
www.ferrisindustries.com
Specifications
TRANSMISSION:
HydroGear 334
Type Unitized Drive Transaxle
Hydraulic Fluid HydroGear 20W-50 oil
Speeds Forward: 0-5.5 MPH (0-8.85 km/h)
@ 3400 rpm Reverse: 0-2 MPH (0-3.22 km/h)
DIMENSIONS:
32” Model
Overall Length 74” (188 cm)
Overall Width 41” (104 cm)
Height 41” (104 cm)
Weight (apx..) 330 lbs. (150 kg)
36” Model
Overall Length 72” (183 cm)
Overall Width 48” (122 cm)
Height 41” (104 cm)
Weight (apx..) 355 lbs. (161 kg)
SPECIFICATIONS
NOTE: Specifications are correct at time of printing and are subject
to change without notice.
ENGINE:
13 Gross HP† Kawasaki Manual Start
Make Kawasaki
Model FH381V
Displacement 26.30 Cu. in (431 cc)
Electrical System 12 Volt Clutch Coil, 13 amp
Oil Capacity 3.2 pt. ( 1.5L) w/ Filter
13 Gross HP† Kawasaki Electric Start
Make Kawasaki
Model FH381V
Displacement 26.30 Cu. in (431 cc)
Electrical System 12 Volt Clutch Coil, 13 amp
Battery: 340 cca
Oil Capacity 3.2 pt. ( 1.5L) w/ Filter
16 Gross HP† Kawasaki Electric Start
Make Kawasaki
Model FS481V
Displacement 36.8 Cu. in (603 cc)
Electrical System 12 Volt Clutch Coil, 15 amp
Battery: 340 cca
Oil Capacity 1.8 US qt. (1.7 L) w/ Filter
15 Kawasaki Electric Start
Make Kawasaki
Model FS481V-DS00-S
Displacement 36.8 Cu. In (603 cc)
Electrical System 12 volt, 15 amp charging coil;
Battery: 340 cca
Oil Capacity 1.8 US qt. (1.7 L) w/ filter
†Power Ratings: All power levels are stated gross horsepower per
SAE J2723 as rated by Kawasaki and tested per the SAE J1995
test standard. The gross power curves and more information can be
viewed at www.kawasaki-criticalpower.com.
CHASSIS:
Fuel Tanks Capacity: 4 Gallons (15.1 L)
Rear Wheels Tire Size: 16 x 6.50 -12
Inflation Pressure: 15 psi (1,03 bar)
Front Wheels Tire Size: 9 x 3.5 - 6
Inflation Pressure: 25 psi (1,72 bar)
