DIVA C24 / C28 / C32
28
FR
cod. 3541E032 - Rev. 00 - 02/2014
5.6 Schéma électrique
fig. 21 - Schéma électrique
A
Attention: Avant de brancher le thermostat d'ambiance ou la chronocom-
mande à distance, détacher le pontage sur le bornier.
32 Circulateur circuit chauffage
34 Capteur de température chauffage
38 Débitmètre
42 Capteur de température eau chaude sanitaire
44 Vanne à gaz
47 Modureg
49 Thermostat de sécurité
72 Thermostat d'ambiance (option)
81 Électrode d'allumage et de détection
95 By-pass
114 Pressostat eau
126 Thermostat fumées
139 Chronocommande à distance (option)
X4
1
2
3
4
5
6
7
114
42
47
38
72
T.
L
N
230V
50 Hz
1
3
2
32
X7
1
44
81
1
2
3
4
5
6
7
8
9
10
11
X2
DBM32
PT1
PT2
49
126
34
T.
PR08205
3.15A 250Vac
2
3
4
139
1 2 3
95
