5.1 Dimensions and connections
7 Gas inlet - Ø 3/4”
8 DHW outlet - Ø 1/2”
9 Cold water inlet - Ø 1/2”
10 System delivery - Ø 3/4”
11 System return - Ø 3/4”
fig. 15- Front view
fig. 16- Side view
fig. 17- Top view - DIVAtech D LN C24
fig. 18- Bottom view - DIVAtech D LN C24 and C30
fig. 19- Top view - DIVAtech D LN C30
700
0
1
2
3
4
400
mm 131 C24
mm 143 C30
330
208
216184
36 65 66 66 65 102
155
10 8 7 9 11
208
202198
