DIVAtech D LN C
39
FR
cod. 3541P710 - Rev. 00 - 09/2018
5.5 Diagrammes
Diagrammes pression - puissance DIVAtech D LN C24
A = GPL - B = MÉTHANE
Hauteur d’élévation résiduelle disponible à l’installation DIVAtech D LN C24
A = Pertes de charge chaudière - 1, 2 et 3 = Vitesse circulateur
Diagrammes pression - puissance DIVAtech D LN C30
A = GPL - B = MÉTHANE
Hauteur d’élévation résiduelle disponible à l’installation DIVAtech D LN C30
A = Pertes de charge chaudière - 1, 2 et 3 = Vitesse circulateur
A
8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26
35
30
25
20
15
10
5
kW
mbar
B
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
6.5
7.0
7.5
8.0
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 1.1 1.2 1.3 1.4 1.5 1.6
H(mCA)
Q (m3/h)
kW
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35
35
30
25
20
15
10
5
mbar
B
A
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
6.5
7.0
7.5
8.0
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 1.1 1.2 1.3 1.4 1.5 1.6
H(mCA)
Q (m3/h)
