Ferroli GN 3 - Page 16

16
GN3
C2
C2
C2
C2
B4
B3
C2
C2
B4
C2
C2
C2
C2
C2
C2
C2
C2
B3
A1
A1
A1
A0
A0
A0
C2
B3
B3
B4
C2
B3
B4
A2
1035
902
769
1833
1700
1567
1434
1301
1168
A2
A2
GN3.06
GN3.07
GN3.08
GN3.09
GN3.10
GN3.11
GN3.12
GN3.13
GN3.14
447
490.0
SECTION A0 A1 A2 C2 B3 B4 Spring Clip
PART. Nr.3844524/0 3844523/0 3844522/0 3422356/0 3844525/0 3844526/0 3430032/0
GN3.06 1 1 1
GN3.07 1 1 1
GN3.08 1 1 1 2
GN3.09 1 1 1 2
GN3.10 1 2 1 3
GN3.11 1 2 1 3
GN3.12 1 3 1 4
GN3.13 1 3 1 4
GN3.14 1 4 1 5
Set of 8 spring clips: part. N° 3980273/0
Composition Water Distribution Pipe
Fig. 27a
Spring clip
HOLE
Example for GN3.09
A1 = Flange section
with 1 hole
C2 = Middle section
with 2 holes
B4 = End section
with 4 holes
