ferrum HYPSOS - Back Panel Overview

A D
F
B C
E
user’s man
4.2. Back Panel Overview
ual
HYPSOS by Ferrum
DC output - here you connect the DC cable. The DC output socket is marked with a red dot. The same
dot is also marked on DC cable. To connect the cable properly both dots must be aligned. To discon-
nect the DC cable, pull the metal ring on the plug in the opposite direction to the device and then pull the
cable out of the socket.
Trigger I/O socket.
Micro-USB port.
Main power switch.
Fuse.
Mains IEC connector. Place mains power cord at this connector.
D.
C.
B.
E.
6
F.
A.
user’s manual
HYPSOS by Ferrum
Figure 2.
