ferrum HYPSOS - Connecting the HYPSOS

nominal
output
12.0 V
output
voltage
12.0 V
output
power
37.1 W
output
current
3.1 A
B
D
user’s man
4.3. Main Screen
ual
HYPSOS by Ferrum
D.
C.
B.
E.
7
F.
A.
C E F
G H
user’s manual
HYPSOS by Ferrum
A
Nominal voltage value set during the process of selecting a device from the list or during manual
configuration.
Measured voltage at the DC HYPSOS output.
Current power consumption of the device powered by the HYPSOS.
Currently measured output current on the DC HYPSOS output.
Voltage adjustment (Sweet Spot Tuning) - this feature can also be set up in the menu.
Menu.
G.
H.
Spread Spectrum Mode icon - when grayed out SSM is not active.
4T Sensing Design icon - when grayed out 4TSD is not active.
Figure 3.
