A. Technical appendix
A−8
Festo P.BE−CPEA−CL−EN en 0711a
Technical data TypeCP−E16−M8−EL, CP−E16−M12−EL
General technical data See section A.1.1
Protection class as per EN 60 529; plug con
nector inserted or fitted with protective cap
IP65
Digital inputs
Configuration 16 inputs per IEC 1131−2 type 2,
24 V DC, positive−switching (PNP)
Logic level:
1−signal
0−signal
>11 V
< 5 V
Current consumption (at 24V) (input cur
rent from sensor to input)
At logical 1"
Typ. 8 mA
Response delay (at 24 V) Typ. 3 ms, can be parametrised: 0.5 ms, 3 ms, 10 ms,
20 ms
Sensor voltage supply
Nominal value
Tolerance
Via the CP connection
24 V DC
See manual for CP master (20.4 V ... 26.4 V)
Internal current consumption of the elec
tronics via the CP connection (all inputs in
0−status)
Max. 75 mA at 24 V
Load capacity Max. 130 mA/ 100 mF per group (electronic
short−circuit protection)
Electrical isolation None
Tab.A/6: Technical data type CP−E16−M8−EL and CP−E16−M12−EL
