A. Technical appendix
A−13
Festo P.BE−CPV−DI02−EN en 0704NH
A.3 Accessories
This section provides an overview of necessary and useful
accessories.
CP valve supply
The power for the CP valves is supplied via a 4pin M12
socket with PG7 or 9 screw connector. These are available
from Festo:
Plug
Type Part no.
PG7 straight FB−SD−GD7 18 497
PG9 straight FB−SD−GD9 18 495
PG7 angled FB−SD−WD7 18 524
PG9 angled FB−SD−WD9 18 525
Bus connection
IP65 field bus plug from Festo (9−pin, Sub−D):
type FBS−SUB−9−GS−DP−B, part no.532216
M12 adapter reverse key coded:
type FBA−2−M12−5POL−RK, part no. 533518
If you wish to use field bus plugs of other manufacturers, you
must replace the two flat screws on the plug by bolts
(partno. 340960).
