Festo CPX-FB36 - Qos Object

C. EtherNet/IP Objects of the CPX-FB36
C-9
Festo P.BE-CPX-FB36-EN en 1309NH English
C.2.2 QoS Object
Object class: 72
d
Instances: 1
IEEE 802.1D/Q describes Ethernet Frames that contain an
additional 32-bit header. This header contains, among other
things, a VLAN ID and a prioritisatio n field.
Attr.
No.
Access Description Type
1 Set 802.1Q Tag enable
Enables or disables sending 802.1Q
frames on CI P and IEEE 1588 mes-
sages
default = 0
US INT
4 Set DSCP Urgent
1)
default = 55
US INT
5 Set DSCP Scheduled
1)
default = 47
US INT
6 Set DSCP High
1)
default = 43
US INT
7 Set DSCP Low
default = 31
US INT
8 Set DSCP Explicit
default = 27
US INT
1) These attributes describe the IP header priority of various Ether-
Net/IP Frames:
Urgent = CI P Motion
Scheduled = CIP Safety
High = I/O
Tab. C/7: Network settings with QoS Object
